Vật liệu của nhà ở: | thép không gỉ 304 | chiều dài của cực: | 490mm |
---|---|---|---|
Hướng quay: | hướng đôi | Điện áp làm việc của động cơ: | DC12V |
Điểm nổi bật: | cổng rào chắn dành cho người đi bộ,cổng vào an ninh,Cửa quay ba chân được gõ dọc |
Functions & Features
Full-automatic type
(1). Stainless steel Housing.
(2). Bi-direction pass.
(3). Arms auto drop when power off.
(4). Arms auto rise up when power on and auto stop on obstacle.
(5). Traffic light indicator.
(6). Wingen 26/Dry contact, is compatible with smart card for access control.
(7). Photoelectric inspection.
(8). If the passenger does not pass in valid time, the passage will be locked up. And the valid passing time can be set up by operator.
(9). Passenger counters (optional).
Model Item |
WJTS122 | ||
Manual, Semi or Full-automatic | Full-automatic | ||
Material of Housing | 304 Stainless Steel | ||
Thickness of Housing | 1.50mm | ||
Dimension of Housing (L×W×H mm) |
420×380×1000 | ||
Length of Pole (out of housing) | 490mm | ||
Net Weight | 50kg | ||
Max Load-bearing of Pole | 80kg | ||
Driving Force of Pole | 3kg | ||
Rotating Direction | Double Direction | ||
Power Supply | 220V±10%, 110V±10% | ||
Frequency | 50/60HZ | ||
Working Voltage of Motor | DC12V | ||
Rated Power | 50W | ||
Driving Motor | Brush DC Motor | ||
Communication Interface | RS232 standard socket/LAN socket | ||
Input Interface | DC12V electrical leveel signal, more than 10ms, or DC12V impulse signal driveing current, more 10mA | ||
Transit Speed | 20~35 persons/min | ||
Working Temperature | 15°C~55°C | ||
Working Environment | Indoor / Outdoor (Shelter) | ||
Relative Humidity | ≤90%, no condensation |
